Project resources · Faqra, Lebanon

Site files

Download the site plan and terrain model for your proposal.

AutoCAD site planDWG file · ZIP download · 0.8 MB 3D topographical modelRhino / 3DM file · ZIP download · 15.9 MB

Unzip each download before opening it in AutoCAD or Rhino.

Reading the site · Parcel clarification

Three parcels. One site.

The competition site comprises 301 Kfertay, 5610 Baskinta and 7942 Baskinta. Read these three parcels together as a single site. The additional lines and neighbouring plots visible in the CAD should not be interpreted as a fourth parcel included in the project.

301Kfertay
5610Baskinta
7942Baskinta

Orientation sketch traced from the supplied AutoCAD view. The white outline identifies the combined site; dashed lines show the internal parcel divisions. Muted linework shows neighbouring and road context. Not to scale; use the downloadable CAD for precise boundaries and dimensions.

Which boundary should I follow?

Follow the combined outer boundary of the three identified parcels. Internal parcel lines do not divide the competition into separate sites. Do not extend the site to the road below where it lies outside this perimeter.

What is the total site area?

The combined site area is 3,146 m², as indicated on the AutoCAD plan. This is the total area of parcels 301 Kfertay, 5610 Baskinta and 7942 Baskinta together.

Site location
